How are touchscreens manufactured?

CDS helps take touchscreen manufacture to the next level

Please find below and in-depth overview of the process and stages involved in touchscreen manufacture including sourcing, testing, quality control and everything needed to create a high quality and reliable touchscreen.

Click here for our PCAP touchscreens

1. Design & Engineering

  • Product Design Specification: Touch technology (e.g., PCAP, resistive), dimensions, interfaces, coatings.
  • Glass and Sensor Design: Optical clarity, strength, electrical performance, and integration.



  1. Raw Material Sourcing
  • Glass Substrate: Sourced from specialty suppliers (e.g., Corning, Schott, AGC etc.).
  • ITO Film or ITO-Coated Glass: For capacitive touchscreens.
  • Adhesives: Optical bonding materials (OCA/LOCA).
  • Controllers & Electronics: Touch controller ICs, cables, sensors.



3. Glass Preparation

  • Cutting: Glass is cut to precise dimensions (CNC or laser).
  • Edge Grinding / Bevelling: Smooth edges to prevent chipping and improve safety.
  • Polishing: Optical-grade surface preparation.
  • Cleaning: Ultrasonic cleaning or deionized water baths to remove particles.
medical professional using an LCD touch screen display with gloves on for hygiene
pcap-wall-mounted-touch-screen-dual-os-windows-android-giant-tablet-34
PCAP Touch Screen Monitor - Application Image (2)
Click here for our case studies page

4. Cover Glass Treatments (as required)

  • Chemical Strengthening: Ion exchange process (e.g., Gorilla Glass) to increase durability.
  • Thermal Tempering: Heat treatment to enhance impact resistance.
  • Surface Coatings:
    • Anti-Reflective (AR)
    • Anti-Glare (AG)
    • Anti-Fingerprint (AF/oleophobic)
    • UV/IR filtering
  • Silk-Screen Printing: Decorative border printing using ceramic ink, then fired for durability.



  1. Sensor Application (for Touchscreens)
  • ITO Deposition: Indium Tin Oxide applied via sputtering or coating for capacitive sensing.
  • Photolithography / Etching: Defines the sensor matrix on the glass.
  • Laser Patterning: Alternative to photolithography for sensor traces.
  • Metal Mesh or Nano-Wire Deposition (for large format or high-res touchscreens)



  1. Optical Bonding or Lamination
  • Lamination: Sensor + cover glass + other layers are laminated using:
    • OCA (Optically Clear Adhesive) or
    • LOCA (Liquid Optical Clear Adhesive)
  • Vacuum Lamination: Eliminates bubbles and improves bonding uniformity.
  • UV Curing / Heat Curing: Final hardening of adhesives.
Monitor Builder CTA
8. Quality Control & Testing (Interwoven at Key Stages)
  • Visual Inspection: For scratches, chips, bubbles, coating defects.
  • Dimensional Measurement: Tolerance checks with digital callipers or CMMs.
  • Electrical Testing:
    • Continuity and resistance checks
    • Touch sensitivity and accuracy
    • Linearity and ghosting
  • Optical Testing:
    • Transmission rate
    • Haze and reflectivity
    • Polarizer alignment (if present)
  • Environmental Testing:
    • Thermal cycling
    • Humidity exposure
    • UV exposure
  • Mechanical Testing:
    • Drop test / impact resistance
    • Surface hardness (e.g., pencil test, Mohs scale)
    • Adhesion tests (for bonded units)
  • Functional Testing:
    • Multi-touch capability
    • Gesture response
    • EMI/ESD testing
factory testing displays
cds stretched testing
cds warehouse
9. Final Assembly (if integrated into display unit)
  • Integration of touchscreen with LCD, backlight, and enclosure (if applicable).
  • Final electrical connectivity and calibration.
  • Packaging for shipment with anti-static and shock-resistant materials.



  1. Shipping & Documentation
  • QC Reports: Batch testing records, certificates of conformity.
  • Traceability Tags: Serial numbers, manufacturing dates, batch IDs.
  • Packaging: Dust- and shock-proof packaging, especially for high-end industrial panels.
Interested in our Zytronic Replacements
Taking Touchscreen Manufacturing to the Next Level with CDS

As you can see, touchscreen manufacturing is a highly intricate process that combines precision engineering, advanced materials, and rigorous quality control at every stage. From the initial design concept to final packaging, every step plays a crucial role in delivering a reliable, high-performance product.

At Crystal Display Systems (CDS), we don’t just follow the process—we enhance it. By working closely with world-class material suppliers, leveraging innovative bonding techniques, and applying decades of industry expertise, we help our customers bring their touchscreen projects to life with unmatched quality and efficiency.

Whether you’re developing a bespoke industrial touchscreen, a retail solution, or a next-gen user interface, CDS has the experience, technology, and support to turn your vision into reality.
