Touch Interactive Stretched Displays

CDS are offering the brand-new LG stretched LCD displays with in-built PCAP touch, including the 23.1” smart shelf and the 29” smart elevator.

The first of their kind interactive smart shelf / elevator driven by in-cell touch, bringing a new experience for consumers.

Key Features and Benefits of Interactive Stretched LCD

  • Low-cost in-built 10-point PCAP touch
  • Ideal brightness for retail applications – 500 & 700 nits
  • Usage in portrait or landscape
  • Android 7.1.2 operating system
  • IPS panels
  • Anti-glare, 4H glass
  • Multiple inputs

CDS LG smart shelf display

Applications can be seen in
  • Smart elevator buttons
  • Interactive smart shelves in retail stores
  • Smart table ordering in a restaurant
  • Smart mirrors in retail shops
  • Vending machines
  • Slim ordering kiosks in fast food restaurants
  • And so much more
Multiple In-Store Retail Applications, Not Just Simply Shelf Edge
Restaurant Applications can Include Food Ordering Totems or Tables
More In-Cell Touch Options

As well as the retail-focused 23.1” and 29”, we also have the below LG in-cell touch panel and kits for integration, including a 4K option.

  1. 10.25” (LA103WF4-SL02)

1920×720, LVDS, 900 cd/m2, Wide Viewing Angle, -40 to +85 Degree Celsius Operating Temperature, I2C type In-Cell Touch (USB type by additional option)

  1. 12.3” (LA123WF4-SR08)

1920×720, RSDS interface instead of LVDS, 700 cd/m2, Wide Viewing Angle, -40 to +85 Degree Celsius Operating Temperature, USB type On-Cell Touch (option)

  1. 14.5” (LA145WF1-SL02)

2560×720, LVDS, 675 cd/m2, Wide Viewing Angle, -30 to +85 Degree Celsius Operating Temperature, I2C type In-Cell Touch (USB type by additional option)

In addition to this we can offer open framed solutions for these panels with board conversions for ease in integration.
