Embedded Systems / Boxed PCs
CDS is an industrial equipment supplier and our embedded Boxed PCs are a wide range of boxed embedded SBC solutions designed for use in professional applications. They are compact & cost effective and designed for 24/7 operation in harsh environments. The CDS TBOX a rugged box PC series are specifically designed for, and according to actual industrial, embedded & automation applications. Rugged & compact design, industrial operating -20~+70C temperature range (optional wider operating temperature upgrades available).
| Model | Description | CPU | Dimensions (mm) | Operating Temp |
|---|---|---|---|---|
| TBOX-C630 | Waterproof designed connectors, 2*GLAN, 16GB RAM memory, 64GB military grade secure erase SSD, | Intel 6th or 7th Core i7 CPU processor | 294 x 200 x 60 | -20~+60C |
| TBOX-3630 | Rugged Intel Skylake Processors fan-less PoE industrial BOX PC: 1x mSATA + 1x 2.5-inch SATA SSD/HDD; 5x GLAN (4x Ports support PoE feature); 6x USB; 1 x RS232 + 1x RS232/RS485; 1x HDMI + 1x VGA; 16x Digital I/O; AUDIO | Skylake i7-6500U | 236.5 x 150 x 60 | -20~+70C |
| TBOX-3620 | Rugged Intel Skylake Processors fan-less PoE industrial BOX PC: 1x mSATA + 1x 2.5-inch SATA SSD/HDD; 5x GLAN (4x Ports support PoE feature); 6x USB; 1 x RS232 + 1x RS232/RS485; 1x HDMI + 1x VGA; 16x Digital I/O; AUDIO | Skylake i5-6200U | 236.5 x 150 x 60 | -20~+70C |
| TBOX-3610 | Rugged Intel Skylake Processors fan-less PoE industrial BOX PC: 1x mSATA + 1x 2.5-inch SATA SSD/HDD; 5x GLAN (4x Ports support PoE feature); 6x USB; 1 x RS232 + 1x RS232/RS485; 1x HDMI + 1x VGA; 16x Digital I/O; AUDIO | Skylake i3-6100U | 236.5 x 150 x 60 | -20~+70C |
| TBOX-3601 | Rugged & super slim sealed aluminum box design; • DC 9~36V, with over-current, over-voltage, reserve polarity protection | Intel Skylake Celeron 3855U Dual-core 1.6Ghz | 180 x 125 x 35 | -20~+60C |
| TBOX-3600 | Rugged Intel Skylake Processors fan-less PoE industrial BOX PC: 1x mSATA + 1x 2.5-inch SATA SSD/HDD; 5x GLAN (4x Ports support PoE feature); 6x USB; 1 x RS232 + 1x RS232/RS485; 1x HDMI + 1x VGA; 16x Digital I/O; AUDIO | Celeron 3855U | 236.5 x 150 x 60 | -20~+70C |
| TBOX-2632 | Rugged Intel Processors fan-less industrial BOX PC: 1x mSATA SSD/HDD; 2x GLAN; 4 x USB; 6 x RS232/RS485/RS422 (Self-adaptive); 1x HDMI + 1x VGA; AUDIO | Skylake i7-6500U | 236.5 x 107 x 60 | -20~+70C |
| TBOX-2622 | Rugged Intel Processors fan-less industrial BOX PC: 1x mSATA SSD/HDD; 2x GLAN; 4 x USB; 6 x RS232/RS485/RS422 (Self-adaptive); 1x HDMI + 1x VGA; AUDIO | Skylake i5-6200U | 236.5 x 107 x 60 | -20~+70C |
| TBOX-2612 | Rugged Intel Processors fan-less industrial BOX PC: 1x mSATA SSD/HDD; 2x GLAN; 4 x USB; 6 x RS232/RS485/RS422 (Self-adaptive); 1x HDMI + 1x VGA; AUDIO | Skylake i3-6100U | 236.5 x 107 x 60 | -20~+70C |
| TBOX-2422 | Rugged Intel Processors fan-less industrial BOX PC: 1x mSATA SSD/HDD; 2x GLAN; 4 x USB; 6 x RS232/RS485/RS422 (Self-adaptive); 1x HDMI + 1x VGA; AUDIO | Apollo lake J3355 | 236.5 x 107 x 60 | -20~+70C |
| TBOX-2412 | Rugged Intel Processors fan-less industrial BOX PC: 1x mSATA SSD/HDD; 2x GLAN; 4 x USB; 6 x RS232/RS485/RS422 (Self-adaptive); 1x HDMI + 1x VGA; AUDIO | Apollo lake J3455 | 236.5 x 107 x 60 | -20~+70C |
| TBOX-2312 | Rugged Intel Processors fan-less industrial BOX PC: 1x mSATA SSD/HDD; 2x GLAN; 4 x USB; 6 x RS232/RS485/RS422 (Self-adaptive); 1x HDMI + 1x VGA; AUDIO | Baytrail J1900 | 236.5 x 107 x 60 | -20~+70C |
| TBOX-2630 | Rugged Intel Processors fan-less industrial BOX PC: 1x mSATA+ 1x 2.5” SATA SSD/HDD; 2x GLAN; 6 x USB; 6 x RS232 (Optional with 1x RS485); 1x HDMI + 1x VGA; AUDIO | Skylake i7-6500U | 236.5 x 150 x 60 | -20~+70C |
| TBOX-2620 | Rugged Intel Processors fan-less industrial BOX PC: 1x mSATA+ 1x 2.5” SATA SSD/HDD; 2x GLAN; 6 x USB; 6 x RS232 (Optional with 1x RS485); 1x HDMI + 1x VGA; AUDIO | Skylake i5-6200U | 236.5 x 150 x 60 | -20~+70C |
| TBOX-2610 | Rugged Intel Processors fan-less industrial BOX PC: 1x mSATA+ 1x 2.5” SATA SSD/HDD; 2x GLAN; 6 x USB; 6 x RS232 (Optional with 1x RS485); 1x HDMI + 1x VGA; AUDIO | Skylake i3-6100U | 236.5 x 150 x 60 | -20~+70C |
| TBOX-2420 | Rugged Intel Processors fan-less industrial BOX PC: 1x mSATA+ 1x 2.5” SATA SSD/HDD; 2x GLAN; 6 x USB; 6 x RS232 (Optional with 1x RS485); 1x HDMI + 1x VGA; AUDIO | Apollo lake J3355 | 236.5 x 150 x 60 | -20~+70C |
| TBOX-2410 | Rugged Intel Processors fan-less industrial BOX PC: 1x mSATA+ 1x 2.5” SATA SSD/HDD; 2x GLAN; 6 x USB; 6 x RS232 (Optional with 1x RS485); 1x HDMI + 1x VGA; AUDIO | Apollo lake J3455 | 236.5 x 150 x 60 | -20~+70C |
| TBOX-2310 | Rugged Intel Processors fan-less industrial BOX PC: 1x mSATA+ 1x 2.5” SATA SSD/HDD; 2x GLAN; 6 x USB; 6 x RS232 (Optional with 1x RS485); 1x HDMI + 1x VGA; AUDIO | Baytrail J1900 | 236.5 x 150 x 60 | -20~+70C |
| TBOX-1630 | Extra compact Intel Processors fan-less Embedded BOX PC: 1x mSATA SSD/HDD; 2x GLAN; No serial COM; 4x USB port; 1x HDMI; AUDIO | Skylake i7-6500U | 168.4 x 106.2 x 45 | -20~+70C |
| TBOX-1620 | Extra compact Intel Processors fan-less Embedded BOX PC: 1x mSATA SSD/HDD; 2x GLAN; No serial COM; 4x USB port; 1x HDMI; AUDIO | Skylake i5-6200U | 168.4 x 106.2 x 45 | -20~+70C |
| TBOX-1610 | Extra compact Intel Processors fan-less Embedded BOX PC: 1x mSATA SSD/HDD; 2x GLAN; No serial COM; 4x USB port; 1x HDMI; AUDIO | Skylake i3-6100U | 168.4 x 106.2 x 45 | -20~+70C |
| TBOX-1410 | Extra compact Intel Processors fan-less Embedded BOX PC: 1x mSATA SSD/HDD; 2x GLAN; No serial COM; 4x USB port; 1x HDMI; AUDIO | Apollo lake J3455 | 168.4 x 106.2 x 45 | -20~+70C |
Advantages of CDS Embedded Boxed PCs:
Complete solution – hardware, software, OS & all other required functionality.
VGA / DVI outputs to easily drive TFT monitors and controller cards.
Very easy to integrate as all components are boxed saving time, space and cost.
Can be used to control external devices and offer more functionality
Fully customizable to suit your application in terms of size and performance.
Innovation & Customisation:
CDS focuses on being to be a Turn-key solution provider for Panel IPC and Embedded IPC applications.
With a dedication to technological innovation, CDS provides qualified products as well as timely & reliable technical support, that the clients can rely on so they can safely deploy with ease and confidence, increasing their ability to bring products to market quickly, and decreasing the development costs and internal support required.
You can check out our full range of Industrial Panel PC’s and Embedded SBC Boards
What is Included in CDS Embedded Boxed PCs?
Compliance with Safety & EMC Cetification
Cards which support – Network, serial, CAN Bus, Video Capture, Storage, Sync & Async applications
Industrial grade monitors for harsh environments with 24/7 usage
Rugged laptops and tablets
Touchscreen panel PCs for industrial and retail – utilising the latest Gen Intel CPUs
Rack-mount computers
Fanless embedded systems
Precision timing systems
Industrial rack mount PCs with flexible PCI & PCIe Expansion
Fanless industrial PCs with high performance platform
Windows embedded standard with wireless ethernet, PS2 keyboard, riser card, graphic card, server chassis, industrial server chassis, VX Works and raid solution options
Why work with CDS and CDS Embedded Boxed PCs?
More than 20 years of experience in assembly and integration of industrial computing solutions. Understanding and flexible call-off order systems to help project manage and relieve stress of lead-times and project cash flow
Highly trained and skilled team of technicians and engineers with wide-ranging off-the shelf product ranges for inclusive system design
System build quality and reliability assured using; EN 55032: 2015, EN 55035:2017, EN 61000-3-2:2014, EN 61000-3-3:2013, EN 62368-1:2014, EN 60950-1:2006 +A2:2013, IEC 60950-1:2005+A1:2009+A2:2013, EN 60950-1:2006+A2:2013 certification
Full UK & European Support from CDS Engineers and Manufacturer with fully configured kits for many LCD TFTs to give a direct drive digital system
Long term availability with 12 month EOL notices and Last Time Buys supported including true industrial design manufactured for highest reliability
CDS Embedded Boxed PCs vast range of embedded solutions are built to the highest standards for true industrial applications.
Air purge control panels, class 1 div 2 certified products, industrial touchscreen PCs, daylight readable monitors, sunlight readable OLED, sunlight readable monitors, mini PCI and mini PCI Express, POE screens, TFT backlight drivers, 5.25 SBC, USB 4, Poster LCDs, ecc memory, IP69K monitors, m2 socket and M2 socket 3.
