Easy Access Front Controls and Ports:
Connect your laptop directly to the Interactive Touch Display with no fuss.

infrared interactive whiteboard touch screen display feature icons

Easy to Move Thanks to Optional Trolley Stand:
Either install onto a classroom wall or invest in a fully portable trolley stand – allowing for improved diversity. Use in any classroom you like or even the assembly hall for playing DVDs.

Your Finger Becomes the Mouse:
Use your finger, stylus or anything else as your cursor. Also supports multi-touch, much like a smart phone, creating a whole new opportunity for group leaning and interaction.

Multitude of Advantages over Projectors:
Touch screen solutions have a sharper image and greater contrast, which provides drastically superior readability and doesn’t take its toll on your eyes. Also designed to last 16 times longer than most projector lamps and doesn’t create annoying shadows.

Runs from Laptop or Optional Internal PC:
You can either run the Interactive Touch Display directly from your laptop or invest in an internal PC.

Environmentally Friendly LED Backlight:
LED backlights offer improved brightness, contrast, lifespan and power consumption. Unlike other forms of light this technology is mercury free; making it even more eco-friendly.

Applications:

• Classrooms • Training or activity rooms
• Corporate boardrooms • Broadcasting studios
• Lecture halls • Sports coaching facilities

.

Display Size (WxH mm) 1432.4×807.4
Pixel Pitch (WxH) 0.744×0.744
Resolution 1920×1080
Brightness (cd/m2) 360
Contrast Ratio 5000:1
Viewing Angle 178°
Aspect Ratio 16:9
Colour 1.07 Billion
Response Time (LCD) 8ms
Color Temperature 10000K
Life Time 50,000 hours
Touch Frame Type Dual
Touch Size – Active Area (WxH mm) 1432.4±1×807.4±1
Input Method Finger, Gloved Hand or Opaque Object
Touch Resolution (Interpolation) 32767(W)x32767(D)
Minimum Touch Object Φ5mm
Touch Accuracy ±2mm (Over 90% Area)
Response Time (Touch) Less than 20ms
Touch Durability Unlimited
Touch Activation Force No Pressure Required
Operation System Windows 7/XP/Vista/CE, Linux, Mac, Android
Interface USB
Aspect Ratio 16:9
Overall Screen Size (mm) 1520x910x85.5
Tempered Glass (mm) 5
Light Transmission More than 95%
Speaker 2x15W
Input Port HDMI (x2), AV, YPbPr (x2), PC Audio, USB, Earphone, S Port, VGA
Output Port Audio, AV
Expansion USB (x2), LAN
Input Power Voltage AC 110-240V (50Hz-60Hz)
Power Consumption (W) 280
Standby Consumption (W) Less than 1
Working Temperature 0°C – 45°C
Working Humidity 10% – 80%RH
Accessories Remote Control, AC Power Cable
Optional Extras Internal PC, Wall Mounting Bracket, Trolley Stand

.

For more information or pricing please email info@crystal-display.com or call our main office on +44 (0)1634 292 025.

.
