CDS Taicenn PPC                 CDS panel pc displays                   cds panel pc display





The combination of industrial PC with state of the art performance featuring a high quality and reliable Touch panel with excellent display capabilities which enables the user to concentrate high performance into the smallest package.

Our all-inclusive industrial panel PC range is designed to cover all requirements from compact PCs to high performance, rugged IP65 models meeting multiple industrial specifications which we know are essential to our industrial customers. Touch screen options include resistive, capacitive, SAW and infra-red as well as tempered glass versions with long lifetime supply and support roadmaps ideal for industrial applications.

Need something customised? No problem, CDS can build all our industrial panel PC range to your exact requirements including processor, memory, storage and operating system options so just ask us! All our PCAP panel mount (open frame available) industrial panel PCs in the table below have 4GB RAM + 64GB SSD as standard but other capacities and updates are available. All have USB / HDMI / VGA interfaces and are CE / FCC certified.

as you will see some of our PPCs come packed with Intel Apollo Lake (as well as Baytrail etc.) processing architecture including 10 point multi touch flush displays as well as fanless and wide temperature ranges  allow for seamless application deployment.

We can pre-install software and customise any of our industrial Panel PCs to suit customer requirements.

Standard brightness is 250 nits as standard but higher brightness solutions also available and are simply upgraded, please ask us.

SizePart NumberResolutionNotes
10.4"TPC-PC104C11024 x 768Intel® Celeron® Processor J1900 2.0Ghz
12.1"TPC-PC121C11024 x 768
Intel® Celeron® Processor J1900 2.0Ghz
15"TPC-PC150C11024 x 768
Intel® Celeron® Processor J1900 2.0Ghz
15.6"TPC-PC156C11366 x 768
Intel® Celeron® Processor J1900 2.0Ghz
15.6"TPC-PC156HC11920 x 1080Intel® Celeron® Processor J1900 2.0Ghz, FHD
17"TPC-PC170C11280 x 1024Intel® Celeron® Processor J1900 2.0Ghz
18.5"TPC-PC185C11366 x 768Intel® Celeron® Processor J1900 2.0Ghz
19"TPC-PC190C11280 x 1024Intel® Celeron® Processor J1900 2.0Ghz
21.5"TPC-PC215C11920 x 1080Intel® Celeron® Processor J1900 2.0Ghz, FHD
24"TPC-PC240C11920 x 1080
Intel® Celeron® Processor J1900 2.0Ghz, FHD
10.4"TPC-PC104A11024 x 768Intel® Celeron® Processor J3455 1.5Ghz
12.1"TPC-PC121A11024 x 768Intel® Celeron® Processor J3455 1.5Ghz
15"TPC-PC150A11024 x 768Intel® Celeron® Processor J3455 1.5Ghz
15.6"TPC-PC156A11366 x 768
Intel® Celeron® Processor J3455 1.5Ghz
15.6"TPC-PC156HA11920 x 1080Intel® Celeron® Processor J3455 1.5Ghz, FHD
17"TPC-PC170A11280 x 1024Intel® Celeron® Processor J3455 1.5Ghz
18.5"TPC-PC185A11366 x 768Intel® Celeron® ProcessorJ3455 1.5Ghz
19"TPC-PC190A11280 x 1024Intel® Celeron® Processor J3455 1.5Ghz
21.5"TPC-PC215A11920 x 1080Intel® Celeron® Processor J3455 1.5Ghz, FHD
24"TPC-PC240A11920 x 1080Intel® Celeron® Processor J3455 1.5Ghz, FHD
10.4"TPC-PC104S11024 x 768i-3-6100U 2.3Ghz
12.1"TPC-PC121S11024 x 768i-3-6100U 2.3Ghz
15"TPC-PC150S11024 x 768i-3-6100U 2.3Ghz
15.6"TPC-PC156S11366 x 768i-3-6100U 2.3Ghz
15.6"TPC-PC156HS11920 x 1080i-3-6100U 2.3Ghz, FHD
17"TPC-PC170S11280 x 1024i-3-6100U 2.3Ghz
18.5"TPC-PC185S11366 x 768i-3-6100U 2.3Ghz
19"TPC-PC190S11280 x 1024i-3-6100U 2.3Ghz
21.5"TPC-PC215S11920 x 1080i-3-6100U 2.3Ghz, FHD
24"TPC-PC240S11920 x 1080i-3-6100U 2.3Ghz, FHD
10.4"TPC-PC104S21024 x 768i5-6200U 2.3Ghz
12.1"TPC-PC121S21024 x 768i5-6200U 2.3Ghz
15"TPC-PC150S21024 x 768i5-6200U 2.3Ghz
15.6"TPC-PC156S21366 x 768i5-6200U 2.3Ghz
15.6"TPC-PC156HS21920 x 1080i5-6200U 2.3Ghz, FHD
17"TPC-PC170S21280 x 1024i5-6200U 2.3Ghz
18.5"TPC-PC185S21366 x 768i5-6200U 2.3Ghz
19"TPC-PC190S21280 x 1024i5-6200U 2.3Ghz
21.5"TPC-PC215S21920 x 1080i5-6200U 2.3Ghz, FHD
24"TPC-PC240S21920 x 1080i5-6200U 2.3Ghz, FHD
10.4"TPC-PC104S31024 x 768i7-6500U 2.5Ghz
12.1"TPC-PC121S31024 x 768i7-6500U 2.5Ghz
15"TPC-PC150S31024 x 768i7-6500U 2.5Ghz
15.6"TPC-PC156S31366 x 768i7-6500U 2.5Ghz
15.6"TPC-PC156HS31920 x 1080i7-6500U 2.5Ghz, FHD
17"TPC-PC170S31280 x 1024i7-6500U 2.5Ghz
18.5"TPC-PC185S31366 x 768i7-6500U 2.5Ghz
19"TPC-PC190S31280 x 1024i7-6500U 2.5Ghz
21.5"TPC-PC215S31920 x 1080i7-6500U 2.5Ghz, FHD
24"TPC-PC240S31920 x 1080i7-6500U 2.5Ghz, FHD
15.6"TPC-DCM156C11366 x 768Intel® Celeron® Processor J1900 2.0Ghz
18.5"TPC-DCM185C11366 x 768Intel® Celeron® Processor J1900 2.0Ghz
21.5"TPC-DCM215C11920 x 1080
Intel® Celeron® Processor J1900 2.0Ghz, FHD
15.6"TPC-DCM156A11366 x 768Intel® Celeron® ProcessorJ3455 1.5Ghz
18.5"TPC-DCM185A11366 x 768Intel® Celeron® ProcessorJ3455 1.5Ghz
21.5"TPC-DCM215A11920 x 1080Intel® Celeron® ProcessorJ3455 1.5Ghz, FHD

CDS 15 inch industrial monitorPanel PC with hand touch

Industrial Panel PCs Continued…

SizePart no.Pixelsbright.ProcessorNote
6.5PPC-06-01T3-A640x480600Intel ® Bay Trail-M N2930 SOC Processor 1.83GFanless. Resistive Touch
7PPC-07-C01T1-A800x480350Intel ® Bay Trail-M N2930 SOC Processor 1.83GFanless. Resistive Touch
8.4PPC-5840T-8451920x1080250Intel® Pentium® processor N3710 1.6 GHz (Braswell)Fanless. Resistive Touch
10.1PPC-10PPC01T1-A1280x800300Cortex™-M203 Dual-Core(1GHz)PCT Touch (10 Point)
10.4PPC-10PPCO3T1-A800 x 600250Intel Processor D2550 CPU(1.86GHz)Fanless. PCT Touch (10 point). No aluminium front bezel but all metal chassis type.
12.1PPC-12PPC02T1-A800x600450A20 1GHz Dual-corePCT Touch (10 Point), Android OS
12.1PPC-12PPC01T6-A800 x 600450Intel Celeron J1900  OR Atom N2600Infra Red touch
12.1PPC-12PPC01T9-A800 x 600450A20 1GHz Dual-coreResistive Touch. Android OS.
15PPC-15PPC01T3-A1024x768400Intel i5-2410M Socket G2 (rPGA988B)3M Cache, 2.30 GHzResistive Touch
15PPC-15PPC01T1-A1024x768400Intel ® Atom Processor D525 1.8GHzResistive Touch
15PPC-150-002-A1024x768400Intel i5-2410M 2.30 GHzResistive Touch
15PPC-15PPC03T4-A1024x768400Intel Celeron J1900 OR Atom N2600 Fanless. Resistive Touch. Open Frame type
15PPC-15PPC03NC-A1024x768250Intel Celeron J1900  OR Atom N2600Fanless. NO TOUCH
15PPC-1157E-871-AX1024x768350LGA1155 socket 3rd & 2nd Generation Intel® Core™ i7/i5/i3, Celeron® & Pentium® processorIP65 Compliant front bezel design. 5 Wire resistive Touch
15PPC-1157S-871-AX1024x768350LGA1155 socket 3rd & 2nd Generation Intel® Core™ i7/i5/i3, Celeron® & Pentium® processorIP65 Compliant front bezel design. Resistive Touch
15PPC-1157S-881-AX1024x768250LGA1150 socket 5th/4th Generation Intel® Core™ i7/i5/i3 & Celeron® processor (Broadwell/Haswell)IP65 Compliant front bezel design. 5 Wire resistive Touch
15.6PPC-5153W-834 1920X1080250Intel® Pentium® processor N3710 1.6 GHz (Braswell)Fanless. 5 Wire Resistive Touch.
17PPC-3177T-311 1280x1024350Intel® Pentium® processor N4200 1.6 GHz (Apollo Lake-M)
Fanless. Resistive Touch
17PPC-1177S-881-AX1280x1024250LGA1150 socket 5th/4th Generation Intel® Core™ i7/i5/i3 & Celeron® processor (Broadwell/Haswell)IP65 Compliant front bezel design. 5 Wire Resistive Touch
17PPC-1177S-871-AX1280x1024350LGA1155 socket 3rd & 2nd Generation Intel® Core™ i7/i5/i3, Celeron® & Pentium® processorIP65 Compliant front bezel design. 5 Wire Resistive Touch
17PPC-1177E-871-AX1280x1024350LGA1155 socket 3rd & 2nd Generation Intel® Core™ i7/i5/ i3, Celeron®, Pentium® & Xeon® processorIP65 Compliant front bezel design. 5 Wire Resistive Touch
17PPC-17PPC01TC-A1280x1024250Intel ATOM N2600 Dual core 1.6GHz 32nmFanless, Infra Red Touch
17PPC-17PPC01T9-A1280x1024250Intel Atom D525 1.8GHzInfra Red Touch
19PPC-19PPC02T4-A1280x1024250VIA Nano X2 Dual core 1.2GHzSAW Touch
19PPC-19PPC02T5-A1280x1024250Intel Celeron J1900  OR Atom N2600Resistive Touch
21.5PPC-3217WL-845-AX1920x1080250Intel® Pentium® processor N3710 1.6 GHz (Braswell)Fanless. IP65 flat front bezel and rugged design. PCT Touch
21.5PPC-21PPC01T3-A1920x1080250Intel® Celeron® CPU J1900 @ 1.99GHzFanless, PCT Touch (10 points)
24PPC-24PPC02T1-A1920x1080250CPU Intel i3 2120 LGA1155/3.3GHz/3M Infra Red Touch
24PPC-24PPC01T1-A1920x1080300CPU Intel E7300 LGA775 Core Duo 2.66GHzInfra Red Touch
31PPC-31PPC05T3-A1920x1080400Intel T5800 Socket P Core Duo 2.0GHz3M Capacitive Touch
42PPC-42PPC08T1-A1920x1080400Intel i5 3470S LGA1155/2.90GHzInfra Red Multi Touch
48PPC-48PPC01N1-A1920x3571000Android 4.0.4Ultra Wide, Android OS, Sunlight Readable
55PPC-55PPCxxxx-A1920x1080550Freescale Cortex A9 i.MX 6Android OS, No Touch

Panel PC from CDS 2Panel PC from CDS 1









Glass to Glass Bezeless Panel PC

SizePart no.PixelsBright. ProcessorNote
21.5" ACDS-21PPC01T31920x1080250Intel® Celeron® CPU J1900 @ 1.99GHz
24" ACDS-24PPC01T41920x1080250Intel Bay Trail J1900 CORES 4 2.0GHz

CDS as you can see offers a entry level to high performance rugged range of panel Computer solutions and this stylish  range offer integrators an alternative designs and performances whether that be rugged industrial or sleek sealed operator interfaces.  the CDS range offers affordable and reliable quality Panel PCs that are used in Human Machine Interfaces (HMI), home automation, Building control, factory automation, process control, SCADA and CAN BUS.

Our new generation of Panel PCs are very impressive utilising powerful technology as well as attractive designs. Users of the CDS products can reliably utilise operating and monitoring processes etc. in your systems.

CDS panel pc inputs Panel PC from CDS CDS panel pc ranges

For more information please email info@crystal-display.com or call our main office on +44 (0) 1634 327 420

Example of ordering information / part numbering:





















We also offer ODM & OEM products.



CLICK HERE FOR MORE INFORMATION ON OUR CUSTOMISATION CAPABILITIES





As you will see CDS’s wide range of Industrial embedded Touch screen PCs includes many variations and options including:

TFT screens, sunlight readable monitors, embedded computer solutions, optical bonding services, Litemax, 15 industrial touch screen PC, Intel Sandy Bridge, Industrial touchscreen PC, rugged touch panel pc, panel mount touch screen pc, 15 panel pc touch screen, panel pc touch screen, fanless panel pc touch screen, multi touch panel pc, touch panel pc, fanless touch panel pc, industrial panel pc touch screen, fanless industrial touch panel pc, flat panel touch screen pc, industrial panel, mounted touch screen pc, industrial panel pc, touch screen price, industrial touch panel pc, industrial touch panel pc computer, systems integrator for smart touch panel pc’s, touch panel HD pc, rugged touch screen computer, Ip67 touch screen, rugged tablet computer,  rugged touch screen pc, rugged touch, screen tablet pc, touch screen rugged pc, industrial panel computer, industrial touch screen pc, industrial touch panel, 15 industrial touch screen pc, panel mount touch screen pc, touch panel computer, pc touch, touch screen pc, touch screen panel, HMI touch screen panel, industrial touch screen, pc touch screen, touch screen, touchscreen, panel computer definition, wall mounted touch screen computer, HMI panel, panel pc windows 7, ip65 pc, industrial touch screen monitor, Touch Screen Panel PCs & HMIs, Rack Mount PCs, Touch Screen Industrial Panel, HMI Multi Touch Panel PCs, Industrial Touch Screen Panel Pc, Industrial touch screen pc, Industrial Monitors, medical panel PC, HMI/Panel PC, Panel PC / HMI, Touchscreen Industrial PC, Industrial Motherboards, TFT display for raspberry pi, Mini ITX PC, industrial LCD panel, LCD controller boards, Rugged Displays & Panel PCs, Panel PCs & Kiosks, Rugged All In One PCs, Touchscreen Panel PCs, Industrial Panel PCs and Touchscreen Industrial Panel PC.



The CDS embedded solutions are covering a wide range of of products, specifications, and options which can also include:

Rugged Industrial Client Computer; Intel J1900; PCAP Touchscreen; IP65; IP68; IP69K; Intel J1900; i7-3610QM; Fully IP Rated Panel PCs; Open-Frame Panel PCs; Industrial Android Based Panel PCs; Touchscreen Panel PCs; Modular Industrial Panel PCs; Fanless Semi-Industrial Panel PCs; Rugged Panel PCs; Intel Bay Trail E3845 processor; IP65 Bezel; Front IP65; 5-Side IP65; Intel Atom Quad Core; ARM TI-AM3354; ARM Freescale i.MX6; Low Power x86; Front IP65/OF; Quad Core Atom; 400MHz x86; Front IP65; Front IP66; i.MX6 DualLite 1.0GHz; 4th Gen Core i3/i5; 6th Gen Core i3/i5; 4th Gen Core i3/i5; IEC 60945; 6th Gen Intel Core i3/i5; Fully IP66/ATEX; Fully IP65/ATEX; 4th Gen Core i5; All-in-one Intel Atom; All-in-one fanless Panel PC; All-in-one Intel Core i; mini-ITX motherboards; Wide Format 1080P LCDs; NEMA 4; NEMA4X Rated Panel Mount; Fully Sealed PCs; Washdown Computers; Fully enclosed computer; Hazardous Area PCs; C1D2 Hazardous Area; Fully Sealed Monitors; NEMA 4 & NEMA 4X Monitors; Intel Skylake Core; Intel Bay Trail Industrial Panel PC; Intel Bay Trail E3845; Industrial Panel PC Touch Screen; Low consumption ‘fanless’ solution; Resistive 4 or 5-wire touchscreen; CPU J1900 2.0 GHz Quad Core processor; front panel mounting; flexible Panel PC SCADA system; Operator Panel; Intel Atom N2600; Aluminium Front/Metal Chassis; Intel Atom N2930; DualLite ARM Cortex A9; Onboard Intel Celeron N2930 (1.83GHz) Processor; Onboard Intel Atom N270 1.6 GHz Processor; Open Frame Design; Touch Screen Support; Fanless Cooling System; IP65 Aluminium Die Cast Front Bezel; Two Easy Access Front USB Ports; Onboard Intel Atom D510 1.66GHz; BayTrail Quad 1.83GHz; Flat P-CAP Maritime; 10.4″ vehicle mount computer; 19″ aluminium panel PC; Heavy Industrial Panel PC; medical panel PC; IP69K Panel PC; In-Vehicle Signage Panel PC; Fully-sealed medical panel computer; 21.5″ Fanless Full IP65/NEMA 4XPanel PC; Intel 5th Generation Core TM i5-5200U 2.2GHz; High-End Industrial Food and Pharma Panel PC; Industrial Panel PC with stainless steel housing; Projected Capacitive Multi finger touch screen; Equipped with an Intel Atom processor D2550; Medical and Industrial Panel PCs; IEC-60601-1; Multi-touch built-in Panel PC; Dual-touch built-in Panel PC; Fanless multi-touch built-in Panel PC; Multi-touch Panel PC; Medical Panel PC’s; high brightness LCD module; medical grade panel PC; Fanless Touch Panel Computer; fanless touch panel computer; anti-vibration design; extended temperature operating ranges; NEMA4x certification; Industrial Panel Computer; easy maintenance back door; SAW touch screen; Open Frame Industrial Panel Computer; Industrial Flat Panel Monitor; waterproof & dust-proof front panels; light duty aluminium panels; multiple mounting modes; industrial flat panel monitor; Harsh and aggressive environments; Medical wipe down; Antibacterial; Panel mounting; Docks, covered decks, the bridge and control rooms; Food preparation, harsh and aggressive environments where water, dust and dirt are present; minimum heat dissipation; reduced noise levels; easy to use within demanding environments; with toughened glass; rugged environment; benign environments; all-in-one concept that integrates a single board computer; industrial-grade machinery computer; fanless power-efficient industrial panel PCs; Intel Quad Core N2930 (Bay Trail); Atom N2600 (Cedar Trail); industrial PCs include 4th gen core with QM87 chipset; feature IET expansion capability; Open Frame PPC; fanless power-efficient; Fan-less Atom N2600 1.6G CPU; 9~36VDC input with adapter; Aluminium chassis; Onboard Intel Bay Trail N2930 (1.83GHz) CPU; Rugged, high-performance, all-in-one industrial panel PCs with brilliant displays; “all-in-one” Panel PC; can be used directly in hazardous areas of Zones 1/21 and 2/22; Outdoor Sunlight-Readable Panel PC; Expandable Cost Effective Intel Celeron Processor J1900 Panel PC; 15″ Heavy-Duty Industrial Panel PC; ARM Based All-In-One Panel PC; ARM-Based Panel PC; Intel Atom Processor E3845 Stainless Steel Panel PC; Intel Atom Processor E3815/E3845 All-in-one Compact Panel PC; 6th Generation Intel Core i3/i5/i7 Processor Expandable Panel PC; with Riser Card Expansion; E3845 Quad-Core Processor-based; Optical Bonding; multifunctional Industrial panel PC products; IP65 stainless steel panel PC; railway EN50155 certified panel PC; sunlight readable; provides OEM/ODM services to produce custom panel PC solutions; compact chassis with multi-functional I/O; based on the latest Intel Core Processors; Industrial Grade Panel PC for Control Rooms; Fanless Railway Driver Console; FlatClient industrial HMI series; stainless steel front for high hygiene standards; Modern industrial design; Human machine interfaces; flexible interfaces; intelligent, intuitive and scalable; robust, reliable, versatile and maintenance-free; Long-term availability; Flexible mounting options; Panel PCs integrated with Projected Capacitive Touchscreen; Integrating it with Resistive or Projected Capacitive Touchscreens; Sealed up to an IP rating of IP69K; Bare or Gloved Fingers; Scratch Resistance Capacity; Display Contrast and Brightness; Dust and Water Resistant; Weather Resistant;
