High Brightness Monitors





Here at CDS we have an amazing range of high bright displays, and high bright monitors for sunlight readable applications.

We have open frame chassis high bright monitors available as well as fully enclosed high bright professional monitors, and sunlight readable monitors.

Open Frame Monitors

Size (")Bright. (nit)ResolutionInputs
6.5” L1000640 x 480VGA, DVI-D
7” L10001024 x 600VGA, DVI-D, HDMI
8.4” L1600800 x 600VGA, DVI-D
10.1” L10001024 x 600VGA
10.4” L10001024 x 768VGA, DVI-D
10.4” L1600 / 2000800 x 600VGA, DVI-D
10.4” L13001024 x 768VGA, DVI-D
12.1” L10001024 x 768VGA, DVI-D
12.1” L1600/20001024 x 768VGA, DVI-D
12.1” L16001024 x 768VGA, DVI-D
13.3” L10001280 x 800VGA, DVI-D
15” L10001024 x 768VGA, DVI-D
15” L1600/2000 1024 x 768VGA, DVI-D
15.6” L14001920 x 1080VGA, DVI-D, DP
17” L10001280 x 1024VGA, DVI-D
17” L16001280 x 1024VGA, DVI-D
18.5” L10001366 x 768VGA, DVI-D
18.5” L16001920 x 1080VGA, DVI-D, HDMI
19” L10001280 x 1024VGA, DVI-D
19” L16001280 x 1024VGA, DVI-D
21.5” L16001920 x 1080DVI-I, DP/ VGA, DVI-D
21.5” L14001920 x 1080VGA, DVI-D
23” L10001920 x 1080DVI-I, DP
24” L10001920 x 1080VGA, DVI-D, HDMI
32” L1200 / 1800 1366 x 768VGA, DVI-D, HDMI
32” L10001920 x 1080VGA, DVI-D, HDMI
32” L25001920 x 1080LVDS
42” L10001920 x 1080VGA, DVI-D, HDMI
43” L1600 1920 x 1080VGA, DVI-D, HDMI
43” L25001920 x 1080VGA, DVI-D, HDMI
43” L10003840 x 2160DVI-D, HDMI, DP
43” L1800 3840 x 2160VGA, DVI-D, HDMI
49" L10003840 x 2160DVI-D, HDMI, DP
49" L16003840 x 2160DVI-D, HDMI, DP
55” L12001920 x 1080VGA, DVI-D, HDMI
55” L14001920 x 1080VGA, DVI-D, HDMI
55” L25001920 x 1080VGA, DVI-D, HDMI
55” L12003840 x 2160VGA, DVI-D, HDMI, DP
65” L20003840 x 2160VGA, DVI-D, HDMI
65” L40003840 x 2160DVI-D, HDMI, DP
75” L30003840 x 2160DVI-D, HDMI, DP

Custom monitors and IP65 monitors also available upon request.

IP65 monitors x 2 with splashcustom openframe monitorsCDS IP66 water resistent monitors

Professional High Bright Product Range:

Display Size32 inch43 inch49 inch55 inch65 inch
Resolution1920 x 10801920 x 10801920 x 10801920 x 10801920 x 1080
Brightness1500 cd/m21500 cd/m21500 cd/m21500 cd/m21500 cd/m2
Unit Size (mm)762 x 458 x 78.5987.2 x 575.1 x 57.2 1121.58 x 651.8 x 58 1275.6 x 746.4 x 101.81478.2 x 854.2 x 117
Weight (KG)11.924.523.23070
Power Consumption180230300340420
Working Temp0 °c to 50 °c0 °c to 50 °c0 °c to 50 °c0 °c to 50 °c0 °c to 50 °c
Additional InputsHDMI, VGA, audio Socket (3.5mm)HDMI, VGA, audio Socket (3.5mm)HDMI, VGA, audio Socket (3.5mm)HDMI, VGA, audio Socket (3.5mm)HDMI, VGA, audio Socket (3.5mm)

CDS high bright LCD displaycds high brightness summercds high bright installcds ultra high bright displays

Ultra High Brightness Professional Monitor Product Range:

Display Size46 inch55 inch65 inch
Resolution1920 x 10801920 x 10801920 x 1080
Brightness2500 cd/m22500 cd/m22500 cd/m2
Unit Size (mm)1080.5 x 635.1 x 132.71272.6 x 734.4 x 132.81491 x 866 x 123.5
Power Consumption380440490
Working Temp0 °c to 50 °c0 °c to 50 °c0 °c to 50 °c
Additional InputsHDMI, VGA, audio Socket (3.5mm)HDMI, VGA, audio Socket (3.5mm)HDMI, VGA, audio Socket (3.5mm)

Sunlight Readable

Brightness is essential when using displays in direct sunlight / outdoor applications.sunlight readable High Brightness Monitors

Our displays use commercial grade Ultra High Brightness panels (1500 cd/m2); more than 3 times brighter than a standard home TV to allow easy readability in direct sunlight.

Integrated Media Playerplug and play sunlight readable High Brightness Monitors

The High Brightness Professional Monitors come with a built in HD media player, allowing you to update them using a USB memory stick. Load your pictures and videos onto a USB memory stick then insert it into the display, which will copy the files into its internal flash memory. Once you remove the memory stick the screen will then start playing the pictures and videos in a continuous loop.

Advanced Temperaure Controltemperature control sunlight readable High Brightness Monitors

The internal air-conditioning system allows the screens to be in constant use in an outward facing window. Internal fans keep their panels and other internal components at the optimum working temperature; ensuring a long and reliable life for your screens.

Commercial Grade Componentscommercial grade components sunlight readable High Brightness Monitors

Fitted with a commercial grade panel, with a lifespan of 50,000 hours, and using high quality components ensures that the displays can be in constant use 24/7.

Integrated Audiospeakers sunlight readable High Brightness Monitors

The displays have two integrated slimline speakers for applications that involve an audio element.

Power Timerpower timer

The eco-friendly power timer allows you to assign daily or weekly on and off times for your screen. The ability to power on and off automatically means that the screen is only in use when it needs to be; improving your environmental efficiency.

Optional Network Upgradewifi version

For a small charge you can also upgrade your screen to be networked, allowing you to remotely update your screen via LAN, WiFi or 3G.

Take a look at the High Bright Monitors in action in this YouTube video;







CDS high brightness monitors can also include: square monitors, widescreen monitors, double sided monitor, curved touch screen monitors, IP65 and IP66 monitors, Industrial LCD monitors, largest ultra-wide monitor, large capacitive touchscreen monitors, kiosk screens,  weather proof IP66 monitors, kiosk touch monitors, outdoor monitor screens, multi-touch monitor, Dynascan monitors, outdoor digital screen displays,  optical bonding monitors, infrared touch screen monitor, optically bonded monitors, water resistant touch screen monitors, advertising monitors LCD, 2 sided monitor, and 120hz LCD panel monitors.

Other options and variations of the CDS high brightness Monitor range: square HDMI monitor, high brightness LED monitors, waterproof marine monitors, large square monitors, interactive touchscreen monitors,  embedded monitor, commercial LCD Display Monitors, daylight readable monitors, high brightness monitors, video wall display monitors, waterproof touch screen monitors, dual touch screen monitors, open frame high brightness touch monitors, touch screen overlays for monitors, marine LCD Monitors,  and square LCD Monitors,

High brightness monitors come in various sizes as per the tables above including:  17.3 open frame LCD monitors, 70 open frame monitors, monitor LCD 42 inch, 46 inch curved monitors, 86 inch touch screen monitor, 43 inch curved monitors, 42 LCD monitors, 42 inch monitors, 7 inch capacitive touch screen monitors, 12 inch USB Monitor, Samsung 49 monitor, 15 inch LCD Monitors, thin frame monitors, slimline monitors,  IP65 monitors, Samsung TFT monitors, 19 touch screen monitors, glass screen monitor, and 10.4 inch monitor.

For more info on our high brightness monitors, please contact us.

Check out our full range of Open Frame Monitors

Also take a look at our Brand new Stretched Bar monitors
