UART Displays

Startek UART Displays from CDS

CDS is a prominent distributor of Startek UART displays. CDS offers a comprehensive selection of Startek products, catering to the needs of developers, engineers, and companies looking for reliable and high-performing display solutions. With a strong focus on customer satisfaction and technical support, CDS ensures that clients receive the best products and services for their specific applications.

Need To Speak To a Displays Specialist? Contact Us Now

Blank Form (#1)

YOUR DETAILS:

Contact Name

Company Name

Phone Number

Country

YOUR ENQUIRY:

Product of Interest

Components >

Embedded >

Monitors >

Digital Signage >

Transparent >

Project Notes (Size / Application / Resolution / Quantity / Target Price / Special Requirements etc?)

What is a UART Display?

A UART display is a type of display module that communicates with a host device (such as a microcontroller, microprocessor, or computer) using the UART (Universal Asynchronous Receiver/Transmitter) communication protocol. This communication method allows for the transmission and reception of data between the display and the host device using serial communication, which involves sending data one bit at a time over a single data line.

Key Features

Serial Communication:
- Asynchronous: UART does not use a clock signal for synchronization. Instead, it uses start and stop bits to denote the beginning and end of each data packet.
- Two-Wire Interface: Involves two primary lines, TX (transmit) and RX (receive).
Data Transmission:
- Baud Rate: The speed of data transmission is set by the baud rate, which must be the same on both the display and the host device to ensure proper communication.
- Data Frame: Typically consists of a start bit, 8 data bits, an optional parity bit for error checking, and one or more stop bits.

CDS

Crystal Display Systems (CDS) is a prominent distributor of Startek UART displays. CDS offers a comprehensive selection of Startek products, catering to the needs of developers, engineers, and companies looking for reliable and high-performing display solutions. With a strong focus on customer satisfaction and technical support, CDS ensures that clients receive the best products and services for their specific applications.

Startek

Startek is a renowned manufacturer of high-quality displays that integrate seamlessly with UART communication. Their product lineup includes a wide range of display types, such as character LCDs, graphic LCDs, OLED displays, and TFT displays, all designed to meet the diverse needs of various applications. Startek’s commitment to innovation and quality ensures that their displays provide excellent performance, reliability, and ease of use.

Applications

Industrial Automation

Machine Interfaces: Used in human-machine interfaces (HMIs) to display machine status, operational parameters, and error messages.
Sensor Readouts: Visualize data from various sensors such as temperature, pressure, and humidity sensors.
Control Panels: Part of control panels in manufacturing and processing plants, allowing operators to monitor and control processes.

Medical Devices

Patient Monitors: Display vital signs such as heart rate, blood pressure, and oxygen levels in real-time.
Diagnostic Equipment: Used in devices like blood glucose meters and portable ultrasound machines to show test results and diagnostic information.
Therapeutic Devices: Integrated into devices like nebulizers and infusion pumps to display dosage and treatment parameters.

Automotive

Dashboard Displays: Provide information such as speed, fuel level, engine status, and warning messages.
Infotainment Systems: Part of car infotainment systems, displaying navigation maps, media information, and control menus.
Diagnostic Tools: Used in automotive diagnostic tools to display error codes, diagnostic data, and system status.

Internet of Things (IoT)

Environmental Monitoring: Display data from IoT sensors monitoring environmental conditions like air quality, temperature, and humidity.
Wearable Devices: Used in fitness trackers and health monitoring devices to display vital statistics and notifications.

How UART Works

Asynchronous: UART does not use a clock signal for synchronization. Instead, it uses start and stop bits to indicate the beginning and end of data packets.
Baud Rate: The speed of data transmission is defined by the baud rate (bits per second).
Data Frame: Consists of a start bit, data bits (usually 8 bits), an optional parity bit for error checking, and one or more stop bits.

Connecting a Display Using UART

To connect a UART display to a microcontroller, follow these steps:

Wiring: Connect the TX pin of the microcontroller to the RX pin of the display, and the RX pin of the microcontroller to the TX pin of the display.
Baud Rate Matching: Ensure that both the microcontroller and the display are set to the same baud rate.
Communication Protocol: Use appropriate commands and data formats as specified by the display manufacturer.
